Baut single glazed, thermal break windows are high quality, high performance windows which
can be manufactured in a variety of shapes and sizes with projected ventilators
where desired. There are three different product offerings in this line with
variations within each to custom specify these windows to individual
architectural needs.
Baut Single Glazed Windows Feature:
Thermal barrier extrusions
Double weather stripping around all perimeters
Glass bead arrangements for various glazing thicknesses
Custom shapes and sizes
Projected ventilators with stainless steel four bar hinges
Pre-glazing available
Shop drawings provided
Templates provided free of charge where needed
Glazing Options:
1/8" to 1 1/4" Monolithic Glass, Insulated Glass, Safety Glass, Plastic or
Architectural Panels
1/2" to 2 1/4" Insulated Glass or Other Glazing Substrates
Baut double
glazed window systems are well suited for new construction or retro-fit work.
These systems are thermally broken and prepared for double glazing. The double
glazing feature allows for interior installation of art glass and exterior
installation of various monolithic glass or polycarbonate glazing options.
Customized to fit each project, sizes, shapes and ventilator options can be
provided in almost any combination.
When Baut provides the art glass and the frames, besides saving money, the
client saves time trying to coordinate between different suppliers. The window
frames can be installed to seal up the building, and to get the certificate of
occupancy. The art glass is installed after the heavy construction is done as
the finishing touch.
Baut Double Glazed Windows feature:
More energy efficient than non-thermal systems
Heavy thermal barrier extrusions
Available with 2 7/8" and 4 1/2" deep profiles
Projected window options include chain pull, project-in hopper type
ventilators (U.S. Patent #302, 324)
Suitable for retro-fit and new construction
Pre-glazing available
Project design assistance available
Custom shapes and sizes
Shop drawings provided
Templates provided free of charge where needed
Glazing Options:
1/8" to 3/8" Monolithic Glass, Safety Glass or Unbreakable Polycarbonate on
Exterior
3/16" to 1" Art Glass on Interior (1/4" Stained/Leaded Glass, 1/2"
Structural Stained Glass, or 1" Faceted Glass)
The Baut
triple glazed window system is the most energy efficient, state-of-the-art
aluminum frame system for new construction or retro-fit work. Customized to fit
each project, sizes, shapes and ventilator options can be provided in almost any
combination.
Handcrafted construction and generous use of materials give these windows a
decidedly monumental appearance.
Baut Triple Glazed Windows Feature:
Highest energy efficiency available
Available with 2 7/8" and 4 1/2" deep profiles
Projected window options include chain pull,
*project-in hopper type ventilators
(U.S. Patent #302, 324)
Suitable for retro-fit and new construction
Pre-glazing available
Coordination of frames with stained glass designers/suppliers
Custom shapes and sizes
Shop drawings provided
Templates provided free of charge where needed
Glazing Options:
5/8" to 1" Insulated Glass Units on Exterior
3/16" to 1" Art Glass on Interior (1/4" Stained/Leaded Glass, 1/2"
Structural Stained Glass, or 1" Faceted Glass)
